High-Speed Microcontroller User’s

Guide: Network Microcontroller

Supplement

SFR D6h

IRAMD

PRAME

—

PDCE7

PDCE6

PDCE5

PDCE4

RT-*

RT-1

RT-0

Multiplier C Register (MC)

R = Unrestricted read, W = Unrestricted write, -n = Value after reset

SFR D5h

MC.7

MC.6

MC.5

MC.4

MC.3

MC.2

MC.1

MC.0

RW-0

MC.7–0
Bits 7–0

Multiplier C register. The multiplier C register is also termed the accumulator register within the math
accelerator. Each time a multiply or divide is performed with the MA and MB registers, the resulting value

is added to the previous value of the accumulator and is then stored back into the accumulator. All shift

or normalization tasks are not added to the accumulator. The MC register is a full read/write register that

provides direct access to the accumulator. The accumulator is 40-bits long and is accessed by five

reads or writes of the MC register. The accumulator is cleared following a system reset, setting the CLMC

bit in the MCNT1 SFR, or by loading five consecutive 00 hex values into the MC register.

A read pointer and a write pointer keep track of which of the five bytes is read or written to when access-

ing or loading the 40 bits of the accumulator. The pointer is set to the most significant byte for reads and

the least significant byte for writes following a system reset, the completion of a calculation, the setting

of the CLM bit, or the setting of the MST bit in the MCNT1 SFR. Following each read of MC, the read

pointer is moved to the next less significant byte until the entire contents of MC are read. Similarly, each

write moves the write pointer to the next more significant byte until the entire 40 bits of the MC register

is written. Neither of the pointers wrap around but rather lock at the extreme end of the associated read

or write 40-bit word size. Note that, in loading or reading a 16-bit (or 32-bit) value, only two (or four)

reads or writes are required. In loading a 16-bit (or 32-bit) value, it is important to make sure that the

remaining 16 bits (or 8 bits) of the 40-bit value are all cleared.

The most significant byte is the first byte read from MC when downloading the contents of a completed

addition of the accumulator, as determined by the MST bit in the MCNT1 SFR. Unlike the MA and MB

registers, data in the accumulator is not cleared during a read. All subsequent reads of MB, after com-

pleting the appropriate reads to secure the respective results of the above calculations, produce the

contents of the fifth byte of data associated with the 40-bit accumulator value. When loading the MC reg-

ister, data must be written with the least significant byte first and most significant byte last.

Memory Control Register 1 (MCON1)

R = Unrestricted read, T = Timed-access write, -n = Value after reset, * = See bit description

IRAMD
Bit 7

PRAME
Bit 6

Bits 5, 4

Internal RAM Disable. IRAMD provides a software option to disable the 64kB internal SRAM. When
IRAMD is 0, the 64kB internal SRAM is active as data or merged program/data memory, dependent on

the logical state of the PRAME bit. When IRAMD is 1, the 64kB internal SRAM is disabled and removed

from the memory map. This bit affects the 64kB internal SRAM only; other internal data segments (the

8kB Ethernet buffer, the 1kB extended stack, and the 256 CAN buffer) are not affected. This bit is only

present on the DS80C410/411 and resets to 0. It is undefined on the DS80C400.

Program RAM Enable. PRAME provides a software selection to use the 64kB internal SRAM as merged
program and data memory. When PRAME is 0, the 64kB internal SRAM is used as data memory only.

When PRAME is 1, the 64kB internal SRAM is mapped to the lower 64kB program and data memory

spaces and functions as both program and data memory. This bit has no meaning when IRAMD is set

to logic 1 which disables the internal SRAM. This bit is only present on the DS80C410/411 and resets to

0. It is undefined on the DS80C400.

Reserved.
