CAN 0 Message Center 2 Control Register (C0M2C)
CAN 0 Message Center 3 Control Register (C0M3C)
CAN 0 Message Center 4 Control Register (C0M4C)
CAN 0 Message Center 5 Control Register (C0M5C)
7
6
5
4
3
2
1
0
SFR ACh
MSRDY
ETI
ERI
INTRQ
EXTRQ
MTRQ
ROW/TIH
DTUP
RW-0
RW-0
RW-0
RW-0
RC-0
R*-0
R*-0
R*-0
R = Unrestricted read, C = Clear only, * = See description, -n = Value after reset
This SFR is not present on the DS80C411.
7
6
5
4
3
2
1
0
SFR ADh
MSRDY
ETI
ERI
INTRQ
EXTRQ
MTRQ
ROW/TIH
DTUP
RW-0
RW-0
RW-0
RW-0
RC-0
R*-0
R*-0
R*-0
R = Unrestricted read, C = Clear only, * = See description, -n = Value after reset
This SFR is not present on the DS80C411.
C0M2C
Bits 7–0
Operation of the bits in this register are identical to those found in the CAN 0 message 1 control regis-
ter (C0M1C: ABh) SFR. Consult the description of that register for more information.
C0M3C
Bits 7–0
Operation of the bits in this register are identical to those found in the CAN 0 message 1 control regis-
ter (C0M1C: ABh). Consult the description of that register for more information.
C0M4C
Bits 7–0
Operation of the bits in this register are identical to those found in the CAN 0 message 1 control regis-
ter (C0M1C: ABh). Consult the description of that register for more information.
C0M5C
Bits 7–0
Operation of the bits in this register are identical to those found in the CAN 0 message 1 control regis-
ter (C0M1C: ABh). Consult the description of that register for more information.
7
6
5
4
3
2
1
0
SFR AEh
MSRDY
ETI
ERI
INTRQ
EXTRQ
MTRQ
ROW/TIH
DTUP
RW-0
RW-0
RW-0
RW-0
RC-0
R*-0
R*-0
R*-0
R = Unrestricted read, C = Clear only, * = See description, -n = Value after reset
This SFR is not present on the DS80C411.
7
6
5
4
3
2
1
0
SFR AFh
MSRDY
ETI
ERI
INTRQ
EXTRQ
MTRQ
ROW/TIH
DTUP
RW-0
RW-0
RW-0
RW-0
RC-0
R*-0
R*-0
R*-0
R = Unrestricted read, C = Clear only, * = See description, -n = Value after reset
This SFR is not present on the DS80C411.
