C-PRO CLIMA SISTEMA INSTALLER MANUAL
Page 65
Panels maintenance
Stag.emergency
Anti-stagnation emergency management mode
- ON/OFF = via a heat disposal ON-OFF valve
- Cover1 = via cover opening closing management (on
same relay contact)
- Cover2 = via cover opening closing management (on
two relay contacts)
ON/OFF ON/OFF Cover2
Panels maintenance
ON hyst.
Offset (differential) solar panels pump connection,
relative to work set-point.
(expressed in °C)
10.0 0.0 50.0
Panels maintenance
OFF hyst.
Offset (differential) solar panels pump disconnection,
relative to work set-point.
(expressed in °C)
5.0 -50.0 50.0
Panels maintenance
Temperature limits
HT setpoint Solar panels circuit water high temperature alarm set-
point
(expressed in °C)
130.0 0.0 200.0
Panels maintenance
Temperature limits
HT hyst.
Solar panels circuit water high temperature alarm set-
point differential, relative to the high temperature
alarm set-point
(expressed in °C)
20.0 0.0 50.0
Panels maintenance
Temperature limits
LT setpoint Solar panels circuit water low temperature alarm set-
point
(expressed in °C)
5.0 -10.0 40.0
Panels maintenance
Temperature limits
LT hyst.
Solar panels circuit water low temperature alarm set-
point differential, relative to the low temperature alarm
set-point
(expressed in °C)
5.0 0.0 10.0
AUX 1 MANAGEMENT
Aux 1 Maintenance
Mode
Auxiliary circuit 1 circulation pump regulation mode:
- CONT. = Continuous
- T.RICH. = On temperature request
T.RICH. CONT. T.RICH.
Aux 1 Maintenance
Contr. probe
Circuit connected with AUX1 for differential
temperature control for AUX1circulation pump
activation:
- DHW = heat exchange with DHW tank
- SOL = heat exchange with solar panel
SOL DHW SOL
Aux1 Maintenance
Setpoint Auxiliary 1 circuit water temperature set-point
(expressed in °C)
60.0 35.0 80.0
Aux1 Maintenance
Hysteresis
Hysteresis (differential) for auxiliary circuit circulation
pump start
(expressed in °C)
5.0 0.0 20.0
Aux1 Maintenance
Offset ON
Temperature differential between control probe and
AUX1 probe for auxiliary circuit circulation pump
activation
(expressed in °C)
10.0 -50.0 50.0
Aux1 Maintenance
Offset OFF
Temperature differential between control probe and
AUX1 probe for auxiliary circuit circulation pump
deactivation
(expressed in °C)
5.0 -50.0 50.0
Aux1 Maintenance
Probe offset Auxiliary circuit 1 probe calibration (offset)
(expressed in °C)
0.0 -10.0 10.0
Aux1 Maintenance
HT setpoint Auxiliary circuit 1 high temperature alarm set-point
(expressed in °C)
70.0 0.0 90.0
Aux1 Maintenance
HT hyst.
High temperature alarm differential (Hysteresis)
relative to the high temperature alarm set-point
(expressed in °C)
5.0 0.0 10.0
Aux1 Maintenance
LT setpoint Auxiliary circuit 1 low temperature alarm set-point
(expressed in °C)
10.0 -10.0 40.0
Aux1 Maintenance
LT hyst.
Low temperature alarm differential (Hysteresis)
relative to the low temperature alarm set-point
(expressed in °C)
5.0 0.0 10.0
