C-PRO CLIMA SISTEMA INSTALLER MANUAL
Page 17
3.4 Regulators network configuration
The c-pro CLIMA system is based on the CANbus communication between the various control
modules present in the network, with the following maximum configuration:
•
N° 1 c-pro Mega MCCT thermal power plant regulator
•
N° 8 c-pro micro MCZN zone regulators
•
N° 8 regulators for additional c-pro micro MCDE dehumidifiers
•
N° 1 regulator for c-pro micro MCPS solar panels
Every controller present in the network must be assigned with a different and specific CANbus
address, according to the logic position of the controller inside the c-pro CLIMA network,
following the layout given below:
Type of controller
Controller code CANbus
address
Thermal power plant regulator c-pro mega MCCT 1 (default)
Zone 1 regulator (zones 1-2) c-pro micro MCZN 2 (default)
Zone 2 regulator (zones 3-4) c-pro micro MCZN 3
Zone 3 regulator (zones 5-6) c-pro micro MCZN 4
Zone 4 regulator (zones 7-8) c-pro micro MCZN 5
Zone 5 regulator (zones 9-10) c-pro micro MCZN 6
Zone 6 regulator (zones 11-12) c-pro micro MCZN 7
Zone 7 regulator (zones 13-14) c-pro micro MCZN 8
Zone 8 regulator (zones 15-16) c-pro micro MCZN 9
Regulator for dehumidif. associated to zone 1 regulator c-pro micro MCDE 22 (default)
Regulator for dehumidif. associated to zone 2 regulator c-pro micro MCDE 23
Regulator for dehumidif. associated to zone 3 regulator c-pro micro MCDE 24
Regulator for dehumidif. associated to zone 4 regulator c-pro micro MCDE 25
Regulator for dehumidif. associated to zone 5 regulator c-pro micro MCDE 26
Regulator for dehumidif. associated to zone 6 regulator c-pro micro MCDE 27
Regulator for dehumidif. associated to zone 7 regulator c-pro micro MCDE 28
Regulator for dehumidif. associated to zone 8 regulator c-pro micro MCDE 29
Regulator for solar panels c-pro micro MCPS 17 (default)
As highlighted in the previous table, the controllers are set by default to be automatically recognised
in network as:
•
thermal power plant regulator CANbus 1 address
•
zone 1 regulator CANbus 2 address
•
regulator for dehumidifiers
added, associated to zone 1 regulator CANbus 22 address
•
regulator for solar panels CANbus 17 address
