C-PRO CLIMA SISTEMA INSTALLER MANUAL
Page 35
Maintenance L1
Mixing valve S
Setpoint 2 Value of the floating delivery 1 set-point relative to the
maximum external temperature in Summer mode
(expressed in °C)
7.0 0.0 40.0
Maintenance L1
Mixing valve S
Fix setpoint Fixed value of the delivery 1 floating set-point in
summer mode if the function is disabled due to alarm
(expressed in °C)
7.0 0.0 40.0
Maintenance L1
Mixing valve W
Mode
Winter mixing valve 1 functioning mode
- Closed
- Modulating
- Openend
MODUL. CLOSED OPENED
Maintenance L1
Mixing valve W
Min.Ext.T. Minimum external temperature in winter for the
calculation of the delivery 1 floating set-point (expressed
in °C)
5.0 -30.0 30.0
Maintenance L1
Mixing valve W
Max.Ext.T. Maximum external temperature in winter for the
calculation of the delivery 1 floating set-point (expressed
in °C)
10.0 0.0 30.0
Maintenance L1
Mixing valve W
Setpoint 1 Value of the floating delivery 1 set-point relative to the
minimum external temperature in Winter mode
(expressed in °C)
35.0 0.0 90.0
Maintenance L1
Mixing valve W
Setpoint 2 Value of the floating delivery 1 set-point relative to the
maximum external temperature in Winter mode
(expressed in °C)
25.0 0.0 90.0
Maintenance L1
Mixing valve W
Fix setpoint Fixed value of the delivery 1 floating set-point in winter
mode if the function is disabled due to alarm (expressed
in °C)
35.0 0.0 90.0
Maintenance L1
M.Valve regulation
Prop. Band
Mixing valve 1 regulation proportional band (expressed
in °C)
5.0 0.0 10.0
Maintenance L1
M.Valve regulation
Integr. time
Integral time for regulation of mixing valve 1 (expressed
in seconds)
0 0 65535
Maintenance L1
M.Valve regulation
Fix opening
Valve 1 opening percentage with fixed opening
regulation (expressed as % opening)
20.0 0.0 100.0
Maintenance L1
M.Valve regulation
Opening time
Opening time valve 1 (sec) 150 0 3600
Maintenance L1
M.Valve regulation
Extra time
Extra time of limit switch open / close valve 1 (sec) 5 0 600
Maintenance L1
M.Valve regulation
Min variation
Percentage of minimum variation of valve 1 to enable
the movement (expressed in % of opening)
2.0 0.0 20.0
Maintenance L1
M.Valve regulation
Antigrip enab.
Enabling of activation of mixing valve 1 for anti-grip
cycle
Yes No Yes
Maintenance L1
Mix V regulation
Antigrip open
Opening percentage of mixing valve 1 during antigrip
cycle (expressed in % of opening)
100.0 0.0 100.0
Maintenance L1
Temperature limits
HT setpoint
Delivery 1 high temperature limit for delivery high
temperature alarm activation (expressed in °C)
45.0 0.0 90.0
Maintenance L1
Temperature limits
HT hyst.
Hysteresis (differential) relative to delivery 1 high
temperature limit (expressed in °C)
5.0 0.0 10.0
Maintenance L1
Temperature limits
LT setpoint
Delivery 1 low temperature limit for delivery 1 low
temperature alarm activation (expressed in °C)
10.0 -10.0 40.0
Maintenance L1
Temperature limits
LT hyst.
Hysteresis (differential) relative to delivery 1 low
temperature limit (expressed in °C)
5.0 0.0 10.0
