C-PRO CLIMA SISTEMA INSTALLER MANUAL
Page 36
Maintenance L1
Probes calibration
Temperature
Delivery 1 temperature probe calibration
(expressed in °C)
0.0 -10.0 10.0
* The same menu is also available for the delivery 2 line
5.9.2 List of INSTALLER menu configuration parameters
Label
Parameter description Default Min Max
I/O CONFIGURATION
I/O configuration
Analog In.
Configuration of type of analogue inputs NTC NTC NTC
I/O configuration
Digital In.
Digital inputs polarity configuration
NC = normally closed
NA = normally open
N.O. N.C. N.O.
I/O configuration
Analog out.
Configuration of minimum and maximum calibration
values of the analogue outputs (expressed as % of the
analogue value in output)
0.0 0.0 100.0
GENERAL PARAMETERS
General parameters
Number of zones Setting the number of zones present in the system
1 0 16
General parameters
Number of MCZN
modules Setting the number of zone MCZN modules present in
the system
1 0 8
General parameters
Delivery lines
Setting the number of delivery lines present in the
system
1 0 2
General parameters
Enable boiler
Enabling of boiler presence Yes No Yes
General parameters
CH-HP type
Setting the type of cooling unit present
--- = not present
CH = chiller
CHHP = chiller/heat pump
CH --- CHHP
General parameters
Enable MCPS
Enabling of MCPS solar panels module presence No No Yes
General parameters
HP-Boiler switch
Switch temp.
Minimum temperature threshold relative to the external
temperature for switch functioning from heat pump
functioning at boiler (expressed in °C)
7.0 -20.0 30.0
General parameters
HP-Boiler switch
Hysteresis Hysteresis (differential) relative to the external
temperature for return to functioning with heat pump
(expressed in °C)
5.0 0.0 10.0
General parameters
HP-Boiler switch
HP max. time
Heat pump activation continuous maximum time for
automatic switch to boiler (expressed in hours)
3 0 65535
General parameters
CANBUS network
Node address
MCCT regulator CANBUS address 1 1 127
General parameters
CANBUS network
Vgraph enab.
Enabling of public V-Graph presence Yes No Yes
General parameters
MODBUS network
Idx
MCCT regulator MODBUS address 1 1 247
General parameters
MODBUS network
Baud MCCT regulator MODBUS communication speed
1200 baud
2400 baud
9600 1200 19200
