C-PRO CLIMA SISTEMA INSTALLER MANUAL
Page 47
Zone A Maintenance
Dehumidifier Alarm
Reset type
Zone A dehumidifier alarm reset type
-AUTOMATIC
-MANUAL
AUTOMA
TIC
AUTOMA
TIC
MANUA
L
Zone A Maintenance
Dehumidifier Alarm
Delay
Zone A dehumidifier alarm delay
(expressed in seconds)
0 0 1
* The same menu is also available for Zone B
6.7.2 List of INSTALLER menu configuration parameters
Label
Parameter description Default Min Max
I/O CONFIGURATION
I/O configuration
AIn1 and AIn2
Type of measure input for analogue inputs 1 and 2 NTC NTC NTC
I/O configuration
AIn3 and AIn4
Type of measure input for analogue inputs 3 and 4 4-20mA NTC 4-20mA
I/O configuration
DIn 1…4
Type of contact for digital inputs
NA = normally open
NC = normally closed
N.C. N.C. N.O.
GENERAL PARAMETERS
General parameters
Local zones nr. Number of zone controlled by MCZN module
2 0 2
General parameters
V-GRAPH mode
Method of using V-Graph display
- UNIV.= Public terminal
- AB= Module private terminal
- A+B= Terminal with no zones
UNIV. UNIV. A+B
General parameters
MCZN module nr. MCZN regulator "logic" position setting in the regulators
network
1 0 8
General parameters
CANbus Address
CANbus serial address 2 0 255
General parameters
Baud rate
CANbus communication speed (baud rate)
-20Kbit
-50Kbit
-125Kbit
-500Kbit
125Kbit 20Kbit 500Kbit
General parameters
MODBUS serial port
Idx
Modbus serial address 1 1 247
General parameters
MODBUS serial port
Baud
Modbus communication speed (baud rate)
- 1200Kb
- 2400Kb
- 4800Kb
- 9600Kb
- 19200Kb
9600Kb 1200Kb 19200Kb
General parameters
MODBUS serial port
Parity
Type of Modbus communication parity
- NO
- ODD
- EVEN
EVEN NO EVEN
General parameters
MODBUS serial port
Stop
Modbus communication Bit Stop position 1b 1b 2b
ZONES SETUP
Zone A setup
Plant Zone Zone A "logic" number with respect to total number of
zones present in the system
1 1 16
Zone A setup
Delivery line
Delivery line (from MCCT) associated to Zone A 1 0 2
