Default Directory Devices
For Network Edition, each time a server is added , three directory devices are automatically configured. This
is mainly done to provide default backup options that illustrate the special naming convention for the
physical directories and how that affects the location and sharing of the backup files. Those directories are:
•
/backups/data/%G/%C Non-system backups placed in a private directory for each group and
client. These backups are not shared among clients.
•
/backups/system/%G/%C System backups placed in a private directory for each group and
client. These backups are not shared among clients.
•
/backups/system/%G/shared System backups placed in a directory for each group, not shared
among groups. However, all client backups are in one directory that
other clients in the same group can read (unless you specify
host
read-only permission for each backup). These backups are suitable
for cloning one client system onto another or sharing of backup data.
You do not have to use any of these devices, and can remove them as long as they are not already assigned to
a backup job. See
Separating Backups by Group and Client above for more on the %G and %C notations.
Change a Backup Device
To change an existing device, select one of the following:
1. Configure !Backup Devices from the menu bar. Select the server and device from the drop-down lists
at the top.
2. When Clients, Servers and Devices are shown in the Main Screen (Network Edition), click on a
server, then the desired device, then press the Change button below.
3. Configure !Servers (Network Edition). From the server configuration screen, select a device from the
Device listbox, then Edit button directly below.
The Device Configuration screen will appear. Make the desired changes and press the Save button to save and
clear the options from the screen.
Remove a Backup Device
To remove an existing device, select one of the following:
1. Configure !Backup Devices from the menu bar. Select the server and device from the drop-down lists
at the top, then press the Remove button at the bottom of the screen.
2. When Clients, Servers and Devices are shown in the Main Screen (Network Edition), click on a
server, then the desired device, then press the Change button below. When the Configure Devices
screen displays, press the Remove button at the bottom of the screen.
3. Configure !Servers (Network Edition). From the server configuration screen, select a device from the
Device listbox, then Edit button directly below. When the Configure Devices screen displays, press the
Remove button at the bottom of the screen.
