18 Chapter 2 Acuity System overview Welch Allyn Acuity Central Monitoring System
System screen views
You can change the screen view of the Acuity Central Station display by clicking these
buttons along the top left of the Acuity Central Station screen. Your system includes some
or all of these choices.
If your system includes multiple screens, the additional screens show Waveform
Windows or Virtual Monitors.
Button Description
Map View
Expands the map to cover most of the Acuity Central Station screen. Map shows
room locations and status icons of all monitored patients. One Virtual Monitor and
review window cover part of the map.
The 4-waveforms view shows four Waveform Windows, two utility windows and
one Virtual Monitor. A utility window can cover the map.
If your system includes multiple screens, this view can show two utility windows
and one Virtual Monitor.
8-Waveforms View
Shows eight Waveform Windows and one Virtual Monitor. A utility window can
cover the map.
12-Waveforms View
Shows 12 Waveform Windows. A Virtual Monitor can cover the map and can be
replaced by a utility window.
Half Screen Review View
The top half of this view shows a review window and the bottom right quarter of
the screen shows four Waveform Windows. The map in the bottom left quarter
might be covered by a Virtual Monitor or utility window.
If your system includes multiple screens, a Virtual Monitor replaces the Waveform
Windows.
Full-Screen Review View
Shows one review window for one patient.
All Monitors View
Shows three Virtual Monitors and one utility window that can cover the map;
shows no Waveform Windows.
4-Waveforms
View 2-Utilities
View
