Directions for use Chapter 11 Specifications 197
Table 41. Review window — Waveforms
Features Factory default
Display priority of waveforms Up to five (ten in the full-screen review view) monitored within the last 24 hours in
following order of priority:
1. ECG
2. P1
3. P2
4. P3
5. P4
6. CO
2
7. RESP
8. SpO
2
Period displayed 25 mm/s; period depends on sweep speed
The most recent seconds monitored appear at the right side of the window, or if
another review window was viewed first, the period is centered around the cursor bar
position in the first-viewed review window.
ECG lead, RESP lead and CO
2
labels to the right of the
waveform display
Reflect labels selected at the monitor during the current time position of the cursor
bar.
Propaq LT monitor lead selections are independent from Acuity System lead
selections.
Presets values ECG scale, 1 mV
Sweep speed
25 mm/s
P1 range 30 mmHg to 180 mmHg
P2 range 0 mmHg to 50 mmHg
P3 range 0 mmHg to 50 mmHg
P4 range 0 mmHg to 50 mmHg
CO
2
range 0 mmHg to 60 mmHg
SpO
2
scale 1x
RESP scale 2x
Blue cursor bar shows Event types. Event markers are arrhythmia types, Arrhythmia and ST Relearn or
Learning Done and snapshot print.
ECG beat labels Normal ( • ) and ventricular ( v )
If Acuity System includes Arrhythmia Analysis option, beat labels appear for
waveforms displayed at sweep speeds between 6.25 mm/s and 50 mm/s
24-hour (or up to 96-hour) time
line indicates patient or
equipment state Time line color matches icon color at all points in time
Printouts Waveforms
Custom
All Leads
