140 Chapter 9 Status icons Welch Allyn Acuity Central Monitoring System
Alarm Tone Suspended
with No Violation
Beneath alerts
and alarms Locations representing
monitors with audible
alarm tones suspended
when no alarm or alert
violation has occurred. None At the patient monitor,
press the Silence/Reset
key when ready.
Or
At the central station,
click Resume in the
patient’s Virtual Monitor
when ready.
color reflects current
status of monitor
Wireless
When the View Wireless
button is pressed in the
lower left corner of the
Acuity Central Station
screen, this icon appears
in map locations where
wireless monitors are
actively communicating
with Acuity System. None
Unconfirmed Patient ID
Low-level alert Locations representing
monitors with
unconfirmed patient IDs. None In the patient’s Virtual
Monitor, click Setup,
Patient ID.
Confirm or enter ID
information
Unconfirmed Room
Number
Low-level alert Wireless monitor map
areas, representing
patients with unassigned
or unconfirmed room
numbers. None In the patient’s Virtual
Monitor, click Setup,
Patient ID.
Confirm or enter a room
number.
Some Alarm Limits Off
Low-level alert Locations representing
monitors with alarming
for some vital signs set
to off. None In the patient’s Virtual
Monitor, click Setup,
Alarms.
Set at least one upper and
lower “limits-pair” per
active vital sign.
Table 8. Icons and messages that represent patient and monitor status
Patient/monitor
status icon Icon display
priority Icon location on map Messages in
hallway message
panels and at top
of Acuity Central
Station screen Recommended action
