A- 12
E850229 SO239 Ant Connector Assembly Bag (in K3 RF Misc Bag)
ILLUSTRATION DESCRIPTION QTY
ELECRAFT
PART NO.
SO239 (UHF) Female Panel Mount
Connector with cable
1 E850229
Screw, 4-40, 1/4” (6.4 mm) Black, Pan
Head
2 E700009
Lock Washer, #4, Inside Tooth 2 E700010
Nut, 4-40 2 E700011
E850238 KIO3A Hardware Bag
ILLUSTRATION DESCRIPTION QTY
ELECRAFT
PART NO.
Screw, 4-40, 1/4” (6.4 mm) Black, Pan
Head
4 E700009
Screw, 4-40, 1/4” (6.4 mm) Zinc, Pan
Head
2 E700005
Lock Washer, #4, Inside Tooth 2 E700010
Jackscrew Nut, 4-40
Note: Two of the jackscrew nuts may be
mounted on the DB-9 connector on the
Remote I/O Board.
4 E700078
Standoff, 4-40, 1-1/4” (31.8 mm) long 2 E700119
