Appendix A Illustrated Parts List
Your kit contains a number of envelopes, boxes and packages of parts. Check the contents of each one carefully
against the following lists. Doing so will not only ensure no parts are missing, but it will also familiarize you
with the appearance of each part that helps the kit assembly go smoothly and quickly.
You may find extra small parts included in your kit. The quantities specific are those required. Also there is a
small bag marked Spares containing more extra parts. If a part is missing, contact Elecraft for a replacement (see
Customer Service and Support on page 1).
Parts for Your Specific Kit
Depending upon the options you chose for our K3, certain parts may be supplied or omitted as needed. One of
the first things you removed from the box was a smaller box containing these parts as described below. Some
options such as the KPA100 KAT3 Automatic Antenna Tuner are supplied in separate boxes with their own
parts lists. They are not shown here. As you assemble your K3, you will be directed to install those options or
prepare your K3 for them to be installed after initial testing and checkout at the proper points in the assembly
procedure.
ILLUSTRATION DESCRIPTION QTY
ELECRAFT
PART NO.
KANT3 Antenna Input
Module.
Not supplied if you
purchased the KAT3
automatic antenna tuner
option with your K3 kit.
The KAT3 replaces the
KANT3.
NOTE: Not all component
positions on the board are
filled. That is normal, the result
of design improvements.
1 E850248
Panel, Blank (KPA3
Fans)
Not supplied if you
purchased the KPA 100
watt amplifier option with
your K3 kit.
1 E850297
Panel, Blank (KXV3 I/O)
Not supplied if you
purchased the KXV3 I/O
option with your K3 kit.
1 E850296
