73
Mapping Volumes to a Server
Mapping Volumes to a Server
Mapping enables servers to connect to volumes.
Mapping a Volume to a Server
1 In the system tree, select an unmapped volume. Expand the Storage Node if
necessary.
2 From the shortcut menu, select Map Volume to Server. A list of servers is displayed.
Figure 54. Map Volume to Server – Server List
3 Select a server to map to the selected volume(s).
4 Click Continue.
Figure 55. Map Volume to Server Confirmation
5 Click Create Now. The volume is mapped.
