187
Configuring Remote Connections Using CHAP
a Repeat through Step 3 on page 185. The Add Remote Compellent CHAP
Initiators window appears.
Figure 157. Add Remote Port Secret.
b Enter the CHAP Name, Remote Target Secret, and Remote Port Secret for a card
that was configured with a CHAP secret.
c Click Add Now.
Add Remote Compellent Connections from System 2 to System 1
While you are in System 2 (Virtual Port Mode):
1 Select an SCSI folder.
2 From the shortcut menu, select Add iSCSI Remote Compellent Connections. The
Add iSCSI Remote Compellent Connections window appears.
3 Add the IP address of a System 2 card.
4 Click Continue.
5 Add the CHAP Name of the System 1 card.
6 Add CHAP Secret.
7 Click Continue.
8 Select a link speed.
9 Click Continue. The Verification window appears.
10 Click Add Now.
Note If you are connecting to a system in legacy mode, add a remote Compellent
Connection for each card.
