47
Managing HBAs
Managing HBAs
Adding HBAs to a Server from a List
If you added a new card to a server, you can logically identify it to the Storage Center
system.

To add an HBA to a sever
1 In the system tree, select a server.
2 From the shortcut menu, select Add HBAs to Server. The Add HBAs to Server
window appears. In the Connected Controller Ports column, the System Manager lists
the server ports connected to this controller.
Figure 36. Add HBAs to Servers
3 Choose the HBAs you want to display: FC, iSCSI, or only Up connections.
Note When you click Refresh, the System Manager does not scan for new HBAs; it
merely re-displays the current list of HBAs.
4 Select an HBA.
Note If you select an iSCSI HBA, you have the option to create the server using WWNs or
iSCSI Qualified Names (IQNs) for HBAs. Default is iSCSI Name.
5 Click Continue. The Storage Center System Manager asks you to confirm.
6 Click Modify Now.
