48 Storage Center 5.5 System Manager User Guide
Servers
Finding an HBA
1 In the system tree, select a server. From the shortcut menu, select Add HBAs to
Server. The Add HBAs to Server window appears.
2 Click Find HBA. The system asks if the server is already cabled to the network.
• If you click Yes, the system asks you to make sure that the network acknowledges the
HBA.
a Locate and unplug the cable to the HBA on the back of the server.
b Wait 60 seconds.
c Plug the cable going to the HBA back into the server.
d Click Find HBA again.
e Select an HBA. Click Continue. The system asks you to confirm.
• If you click No:
a Plug the server into the FC Network or create a connection by logging on to the iSCSI
portal.
b Wait 30 seconds
c Click Continue.
Note If the system does not see a new HBA, check the cabling and connections. Click
Scan Again.
