57
Viewing Server Information
Viewing a Server Connectivity Report
Note Server Connectivity Report appears only if the system does not have Virtual Ports.
1 From the View menu, choose Server Connectivity. The Server Connectivity view
appears. The left side of the Server Connectivity window lists:
• WorldWide Name (WWN)
• Name of server
• Type of server
• Port type of FC or iSCSI
2 Scroll to the right to view additional information for each server. For each server, the
view displays:
• System to which the server is connected
• Server Port ID
• Fault domain
• Usage: Primary or Reserved
• Server type of FC or iSCSI
Figure 42. Server Connectivity View
System to which server is connected
