357
Printing a Chart
Viewing Disk Charts

To view the disks chart
1 In the Charting Viewer navigation tree, select the disk icon, a disk folder or an
individual disk. The Disk Chart window appears.
2 Click a tab to view:
• Disks IO/Latency
• Disks KB/Latency
Viewing Controller and Local Ports Charts

To view the controller and local ports charts
1 In the Charting Viewer navigation tree, select the Controllers icon, an individual
controller, a port type icon, or an individual port. The Controller/Ports Chart window
appears.
2 Click a tab to view:
• Local Ports IO
• Local Ports Latency
• CPU/Memory (for controllers only)
Printing a Chart

To print a chart
1 Select the chart you want to print, and select Print. The Page Setup dialog appears.
2 Select Page Setup options:
• Paper Size: Select a paper size from the list of available options.
