Dell Compellent Series 30 - Manual (Page 363)

355
Using Charting Viewer
Setting Charting Viewer Properties
1 When the Charting Viewer is displayed, click Properties. The Charting Properties
dialog appears.
2 Select the objects for which you want to gather and display information:
• Volume IO Usage: Retrieves and displays IO statistics for all volumes, volume
folders, and individual volumes.
• Server IO Usage: Retrieves and displays IO statistics for all servers, server folders,
and individual servers.
• Disk IO Usage: Retrieves and displays IO statistics for all disks, disk folders, and
individual disks.
• Controller/Local Ports IO Usage: Retrieves and displays IO statistics for all
controllers, individual controllers, and individual ports on a controller.
Note Charting Viewer always displays System IO Usage.
3 Click OK to close the dialog.
