134 | Using the System Setup Program
Token Setup option Description
4851 Mezzanine Slot
ASPM Controls the level of ASPM supported on Mezzanine Slot.
L0s entry downstream and L1 enabled.
4852
NB-SB Link
ASPM
Controls the level of ASPM supported on the NB-SB. All
entry disabled.
4853
NB-SB Link
ASPM
Controls the level of ASPM supported on the NB-SB. L1
entry enabled.
4854
Maximum
Payload Size
Auto detects the PCI-E maximum payload size.
4855
Maximum
Payload Size
Sets the PCI-E maximum payload size to 128 Bytes.
4856
Maximum
Payload Size
Sets the PCI-E maximum payload size to 256 Bytes.
4857 WHEA Support Disables Windows Hardware Error Architecture.
4858 WHEA Support Enables Windows Hardware Error Architecture.
4859 NIC
Enumeration
Default, Set PXE boot from on-board NIC then Add-on
NIC adapter.
485A NIC
Enumeration Set PXE boot from Add-on NIC adapter then on-board
NIC.
485B PCI-E Generation Set the PCI signaling rate at Gen3 8.0 Gigabits
bandwidth.
485C PCI-E Generation Set the PCI signaling rate at Gen2 5.0 Gigabits
bandwidth.
485D PCI-E Generation Set the PCI signaling rate at Gen1 2.5 Gigabits
bandwidth.
NOTE: The PCI-E Gen2 x16 slot 1 and slot 2 are supported up to Gen2 5.0 Gigabits
bandwidth. If user inserts Gen3 .0 devices into the 2 slots that will only train at Gen
2.0 speed, not Gen 3.0.
