Using the System Setup Program | 119
of BMC LAN port as 10.106.42.120)
Table 2-1. The D4 Token Table
Token Setup option Description
002D
Embedded NIC1 Enables the system’s primary embedded network
interface controller (full-function), including its
PXE boot-ROM.
002E
Embedded NIC1 Disables the system’s primary embedded network
interface controller.
0051
N/A For the next system boot, set the IPL priority to: USB
storage, hard disk, CD/DVD-ROM, RAID, Network (if
the devices are available)
0052
N/A For the next system boot, set the IPL priority to: hard
disk then option ROMs (if the devices are available)
0053
N/A For the next system boot, set the IPL priority to:
Network, hard disk, RAID,USB storage, CD/DVD-
ROM (if the devices are available)
0054
N/A For the next system boot, set the IPL priority to:
CD/DVD-ROM, USB Storage, hard disk, RAID,
Network (if the devices are available)
005C
N/A Enables the BIOS remote update on the next reboot,
to search for an operating-system initiated
BIOS update image.
005D
N/A Disables the BIOS remote update on the next reboot,
to search for an operating-system initiated
BIOS update image.
006E
Embedded NIC1 Enable the system’s primary embedded network
interface controller, but don’t enable the NIC’s
associated PXE or RPL boot-ROM.
0087
Video
Enumeration The onboard video controller is used for boot-time
messages.
0088
Video
Enumeration The first add-in video controller is used for boot-time
messages. Depending on the BIOS search order and
system slot layout.
