196 | Removing and Installing System Components
Figure 3-30. Removing the LSI 9265-8i Card Assembly for 1U Node
1 LSI 9265-8i-card assembly 2 screw (4)
3 system-board assembly
5 Remove the screw securing the LSI 9265-8i card. See Figure 3-31.
6 Grasp the LSI 9265-8i card by its edges, and carefully remove it from
the riser card. See Figure 3-31.
If you are removing the card permanently, install an expansion-card
slot cover over the empty expansion slot opening, and close the
expansion-card latch.
NOTE: You must install a filler bracket over an empty expansion slot to maintain
Federal Communications Commission (FCC) certification of the system. The
brackets also keep dust and dirt out of the system and aid in proper cooling and
airflow inside the system.
