26 | About Your System
Item Indicator, Button
Or Connector
Icon Description
system using the power button
causes the system to perform a
graceful shutdown before power to
the system is turned off.
NOTE: To force an ungraceful
shutdown, press and hold the
power button for five seconds.
System-Board Assembly Configurations
Figure 1-16. Enumeration Four System Boards for 1U Node
Figure 1-17. Enumeration Three System Boards for 1U Node
Figure 1-18. Enumeration Two System Boards for 1U Node
