Using the System Setup Program | 135
Token Setup option Description
485E Reboot on WOL
(ROW)
Disables the ROW in default, Reboot on WOL(ROW) is
a feature which repurposes the traditional Wake on LAN
(WOL) signal to reboot the motherboard. During system
is in S0/S3
state, when a WOL packet is received by the NIC, the
wake‐up signal generated by the NIC
shall cause a hardware reboot of the motherboard.
485F Reboot on WOL
(ROW) Enables the ROW, Reboot on WOL(ROW) is a feature
which repurposes the traditional Wake on LAN (WOL)
signal to reboot the motherboard. During system is in
S0/S3 state, when a WOL packet is received by the NIC,
the wake‐up signal generated by the NIC shall cause a
hardware reboot of the motherboard.
4860 USB PORT with
BMC This feature will allow the users to electrically disable the
internal USB port which contacts to BMC.
4861 USB PORT with
BMC This feature will allow the users to electrically enable the
internal USB port which contacts to BMC.
4870 Force PXE Boot
only
Disables PXE to be the boot device only.
4871 Force PXE Boot
only Enables PXE to be the boot device only. The system
retrying to boot from PXE device.
4873 Active
Processor Cores This field controls the number of enabled 16 cores in
each processor. By default, the maximum number of
cores per processor will be enabled.
4877 PCI-E Slot1 This feature will allow the users to electrically disable
PCI-E Slot1.
4878 PCI-E Slot1 This feature will allow the users to electrically enable PCI-
E Slot1.
4879 PCI-E Slot2 This feature will allow the users to electrically disable
PCI-E PCI-E Slot2.
487A PCI-E Slot2 This feature will allow the users to electrically enable PCI-
E Slot2.
487B PCI-E Slot3 This feature will allow the users to electrically disable
PCI-E Slot3.
487C PCI-E Slot3 This feature will allow the users to electrically enable PCI-
E Slot3.
487F Mezzanine Slot This feature will allow the users to electrically disable
Mezzanine Slot.
