262 | Removing and Installing System Components
Item Cable From
(Power Distribution
Boards)
To
Hard-drive
backplane
power cable Hard-drive backplane
power connector (J84) Backplane
Hard-drive
backplane
power cable Hard-drive backplane
power connector (J29) Backplane
Power
distribution
board cable Control connector (J31) Power distribution
board 2
I2C cables System board control
connectors (J5&J6) Middle planes
Backplane
control cable Hard-drive backplane
control connector (J17) Backplane
System fan
cable System fan connector
(J9) System fans
12V power
cables Power distribution board
1/2 Middle planes
Ground
power cables Power distribution board
1/2 Middle planes
