276 | Removing and Installing System Components
Item Cable From
(Top Middle Plane) To
(Direct Backplane)
Hard-drive
backplane
cable Mini-SAS connector for
system board 1 and 2
(hard drive 1, 2, 3 and 4)
(J1) SATA2 hard drive
connectors 1 to 4 for
system board 1 (from
right to left)
Hard-drive
backplane
cable Mini-SAS connector for
system board 1 and 2
(hard drive 5 and 6) (J2) SATA2 hard drive
connectors 5 to 6 for
system board 1 (from
right to left)
Hard-drive
backplane
cable Mini-SAS connector for
system board 3 and 4
(hard drive 1, 2, 3 and 4)
(J3) SATA2 hard drive
connectors 1 to 4 for
system board 3 (from
right to left)
Hard-drive
backplane
cable Mini-SAS connector for
system board 3 and 4
(hard drive 5 and 6) (J4) SATA2 hard drive
connectors 5 to 6 for
system board 3 (from
right to left)
