Using the System Setup Program | 149
Setup Menu Setting
Maximum
Performance (48DB)
Energy Efficiency
(48DC)
Setup Page Setting Option
D4
Token
Option
D4
Token
Memory Operating
Voltage 1.5 V 02B6 1.35V
/1.25V 02B7
/48B5
SATA
Configuration Embedded SATA
Link State Auto 4834 1.5 Gbps 4835
Power Saving Features Disabled 0199 Enabled 019A
PCI
Configuration PCI-E Slot ASPM Disabled 4840 L0s & L1 4843
Onboard LAN ASPM Disabled 4846 L0s & L1 4849
Mezzing Slot ASPM Disabled 484C L0s & L1 484F
NB-SB Link ASPM Disabled 4852 L1 4853
PCI-E Generation Gen3/Gen2 485B/4
85C Gen1 485D
NOTE: The PCI-E Gen2 x16 slot 1 and slot 2 are supported up to Gen2 5.0 Gigabits
bandwidth. If user inserts Gen3 .0 devices into the 2 slots that will only train at Gen
2.0 speed, not Gen 3.0.
