About Your System | 25
Item Indicator, Button
Or Connector
Icon Description
and system board. Lights amber
when the system needs attention
due to a problem.
5 LAN connector 1 Embedded 10/100/1000 NIC
connectors.
6 LAN connector 2 Embedded 10/100/1000 NIC
connectors.
7 Management port Dedicated management port.
8 Serial port Connects a serial device to the
system.
9 VGA port Connects a VGA display to the
system.
10 Power-on indicator/
system state indicator/
power button The power-on indicator turns to
green when the system power is
on.
The power-on indicator turns to
amber when the system critical
event occurs.
The power button controls the
DC power supply output to the
system.
NOTE: When powering on the
system, the video monitor can take
from several seconds to over 2
minutes to display an image,
depending on the amount of
memory installed in the system.
NOTE: On ACPI-compliant
operating systems, turning off the
