1.2 Parts and controls
766 IC Sample Processor
3
11 Splash protection
(6.2751.040)
Must be installed always in
operation!
15 15 Contact pressure lever
For adjusting the contact pressure
22 Needle
Steel needle (6.2624.000) or
PEEK needle (6.1835.000)
16 16 Holding clamp
For locking the tubing cartridge into
place
33 Lift
With swing head attached
17 17 Snap-action lever
For releasing the tubing cartridge
44 Needle holder
(attached)
18 18 PEEK capillary (6.1831.060; 1 m)
For conveying the sample to the
injection valve of the 733 IC Separa-
tion Center
55 PEEK compression fitting
(4.766.4070)
For peek capillary 88
19 19 Tower
66 PEEK compression fitting
(6.2744.010)
20 20 PE bottle (6.1608.080; 300 mL)
77 Swing head
(attached)
21 21 Connection cable for swing head
Attached, incl. branch plug for remote
connection
88 PEEK capillary (6.1831.050;
40 cm)
Connection needle – pump
tubing
22 22 Remote connection
99 Guide chain
For fixing tubings and cables
23 23 Plug cover (6.2752.010)
10 10 Pump tubing (6.1826.040)
For conveying the sample
24 24 Fuse holder
Changing the fuses, see section 2.2.2
11 11 Screw thread for splash
protection
25 25 Mains connection plug
Mains connection, see section 2.2.3
12 12 Mounting pin
For attaching the tubing
cartridge
26 26 Mains switch
For switching the instrument on/off:
I = ON 0 = OFF
13 13 Tubing cartridge (6.2755.000)
For 6.1826.0X0 pump tubing
27 27 Sample rack (6.2041.430)
14 14 Pump drive
Roller head with contact rollers
28 28 PP sample tube (6.2743.050)
(can be sealed with 6.2743.060 PE
caps)
