4 Operation
766 IC Sample Processor
52
>auxiliaries
beeper: ON
ON,OFF
Acoustic warning signal
ON Acoustic warning signal in case of error
messages
OFF No warning signal
>auxiliaries
device label
8 ASCII characters
Device label
Freely selectable ASCII character string for characteriz-
ing the instrument (text entry, see section 4.1.6).
>auxiliaries
program 5.766.0010
read only
Number of the program version
Display only (no entry possibility).
Please specify this number in inquiries to Metrohm.
>auxiliaries
max. lift way
125 mm
0 … 125 mm
Maximum stroke path for needle
The following entry becomes effective after a RESET or
switching the IC Sample Processor off and on again.
This setting for max. lift way is important for safe op-
eration. If the value for this entry is correct, damage to
the needle can be avoided because this prevents the
needle from being driven lower than the position indi-
cated. If you use the 6.2041.430 sample rack with
6.2743.050 sample tubes, the default value of 125 mm
should be retained.
Pressing directly accepts the current lift po-
sition of the active tower.
configuration
>rack definitions Definition of sample racks
>rack definitions
rack number 2
1 … 16
Number of the rack
The number of the rack in position is automatically dis-
played here, when its configuration is already stored
and when a RESET has been performed. If the con-
figuration of another rack must be changed, its rack
number must be entered and confirmed with
. The rack number will be shown in the first
menu line for the subsequent entries. For more informa-
tion concerning sample racks, see section 4.5. The
number
2
is assigned to the 6.2041.430 sample rack
delivered.
>rack definitions 2
code 010001
6 bits
Identification code of the rack
The rack code must be unique and can only occur once
in the instrument (see section 4.5).
