4.3 Methods
766 IC Sample Processor
65
More detailed information about the syntax can be found in the Instruc-
tions for Use of the instrument from which the status messages should
be transmitted.
With the LEARN function transmitted data (= character strings) can be
taken over interactively (see section 4.3.4).
CTL
2
CTRL
>sample sequence
7 CTL:Rm: INIT
Rm,RS INIT
INIT 732
PROG R/S 1
PROG R/S 2
PUMP R/S 1
FILL A 1
INJECT A 1
FILL B/STEP 1
INJECT B 1
ZERO 1
PUMP 752 ON
PUMP 752 OFF
STEP MSM 753
******0*001***
******0*010***
******1*000***
******0*101***
******1*010***
******0*011***
*******1******
*******0******
14 bit (1,0 or *)
Setting the remote lines
= initialize remote lines of 766
= initialize remote lines of 732/1 and 732/2
= run/stop time program at 732/1
= run/stop time program at 732/2
= run/stop IC Pump 709/1
= switch valve A at 733/1 to "Fill"
= switch valve A at 733/1 to "Inject"
= switch valve B at 733/1 to "Fill" or switch
suppressor to next position
= switch valve B at 733/1 to "Inject"
= trigger the autozero function at 732/1
= switch on pump at 752/753
= switch off pump at 752/753
= switch suppressor at 753 to next position
= run/stop IC Pump 709/2
= switch valve A at 733/2 to "Fill"
= switch valve A at 733/2 to "Inject"
= switch valve B at 733/2 to "Fill" or switch
suppressor to next position
= switch valve B at 733/2 to "Inject"
= trigger the autozero function at 732/2
= switch on pump at 754
(with 6.2143.220 cable)
= switch off pump at 754
(with 6.2143.220 cable)
arbitrary 14 bit pattern
The
CTL:Rm
command controls external instruments via the remote in-
terface. It causes the setting of defined line states or the sending of
pulses via the 14 remote output lines.
Predefined bit patterns are supported which can be selected by short
names (e.g.
'INIT 732'
or
'ZERO 1'
).
Setting particular bit patterns allows flexible control of connected in-
struments.
Here the following is valid:
0
= line inactive
1
= line active
∗
= do not change line state
Example:
***000*******1
= Output line 0 active
= start/stop time program at 732/1
For details about the remote interface, see section 5.1.
2
CTRL
>sample sequence
8 CTL:RS
Rm,RS
Clear value: &D.S"9"
14 ASCII characters
Data communication via
serial RS232 interface
= start/stop time program at 732
arbitrary string of 14 characters
