5.2 RS232 interface
766 IC Sample Processor
103
Object Meaning Entry range/Selection
&Assembly
&A ssembly Assembly control –
³
Ã.
S ample Current sample position $G
³ Ã .
F unc Selection of function = , +, –
³ À .
V alue Value of function 0 … 1 … 999
³
Ã.
M ove Turning the sample rack $G, $S
³ Ã .
T arget Lift address (only '1' possible) 1
³ À .
P osition
³
Position sample , spec1 … spec8,
1 … 999
³
Ã.
L ift Moving the lift $G, $S
³ Ã .
S tation Lift address (only '1' possible) 1
³ À .
W ay
³
Target position rest , work, rinse, shift,
special, 0 … 125 mm
³
Ã.
P ump Pump control $G, $S
³ Ã .
A ddress Pump address (only '1.1' possible) 1.1
³ À .
V alue Time or status 1 … 999 s, on off
³
Ã.
Sc an Scanning the interfaces $G, $S
³ Ã .
A ddress Selection of interface Rm , RS
³ À .
P attern
³
³
³
³
³
Input signal or data
for Rm (Remote):
for RS (RS232):
8 × 1, 0 or * (binary)
ready1 , end1, end2,
wait1, wait2, wait*, pump1 ?,
pump2 ?, pump* ?
14 ASCII characters
³
Ã.
C trl Interface control $G
³ Ã .
A ddress Selection of interface Rm , RS
³ À .
P attern
³
³
³
³
³
³
³
Output signal or data signal
for Rm (Remote):
for RS (RS232):
14 × 1, 0 or * (binary)
INIT , INIT 732, PROG R/S 1,
PROG R/S 2, PUMP R/S 1,
FILL A 1, INJECT A 1, FILL B/
STEP 1, INJECT B 1, ZERO 1,
PUMP 752 on, PUMP 752 off,
STEP MSM 753
14 ASCII characters, &D.S"9"
³
Ã.
W ait Waiting time $G, $S, $H, $C
³ À .
T ime Waiting time 0 … 1 … 9999 s
³
À.
E nd Trigger reset $G
