4.3 Methods
766 IC Sample Processor
63
LIFT
9
LIFT
>sample sequence
3 LIFT: 1 : rest mm
work,rinse,shift,
special,rest,0 … 125 mm
Position the lift
Raising or lowering the lift to a defined position. Work, rinse, shift and
special position are rack-specifically defined in the Configuration menu
under '>rack definitions' (see section 4.2.1).
The rest position is the zero position (0 mm) of the lift, i.e. the upper
stop.
Each lift can also be precisely positioned to the millimeter. The LEARN
function is also available for this purpose (see section 4.3.4).
With LIFT commands, please note that if you are using the 6.1835.000
PEEK needle, the sample tubes may not be sealed with caps be-
cause they cannot be pierced by the PEEK needle !
PUMP
PUMP
4
>sample sequence
4 PUMP 1.1
:
1 s
1 … 999 s,ON,OFF
Pump control
With the command the peristaltic pump of the 766 IC Sam-
ple Processor can be controlled.
The pump can be turned off and on as desired or operated for a spe-
cific amount of time. The LEARN function is useful for determining the
interval of time (see section 4.3.4).
SCAN
1
SCAN
>sample sequence
5 SCN:Rm : Ready1
Rm,RS Ready1
End1
End2
Wait1
Wait2
Wait ∗
Pump1 ?
Pump2 ?
Pump ∗ ?
8 bit (1,0 or ∗)
Scanning the remote
interface
= Waiting until 732/1 is ready
= Waiting for EOD pulse of 732/1
= Waiting for EOD pulse of 732/2
= Waiting until remote line 3 of 732/1 is set to 1
= Waiting until remote line 3 of 732/2 is set to 1
= Waiting until remote line 3 of 732/1 and 732/2
are set to 1
= Waiting until IC Pump 709/1 is running
= Waiting until IC Pump 709/2 is running
= Waiting until IC Pumps 709/1 and 709/2 are
running
any 8-bit pattern
In a sequence the
SCN:Rm
command causes method processing to stop
until the predefined bit pattern is received.
