Metrohm 766 IC Sample Processor - Manual (Page 104)

5.2 RS232 interface
766 IC Sample Processor
99
Object Meaning Entry range/Selection
³
Ã.
F inalSeq Final sequence –
³ Ã .
1 Line number of the command –
³ ³ Ã .
C md
³ ³ ³
³ ³ ³
³ ³ ³
Command (see Start sequence) NOP , MOVE, LIFT, SAMPLE,
PUMP, SCAN, CTRL, WAIT,
ENDSEQ
³ ³ À . *
³ *
³ :
³ ³
³ ³
Parameter for command (see Start sequence) .MOVE … , .LIFT … ,
.SAMPLE … , .PUMP … ,
.SCAN … , .CTRL … , .WAIT … ,
.END …
³ À .
100 Sequence end NOP
³
Ã.
C hanger Changer settings –
³ Ã .
R ackNo Rack number 0 … 16
³ Ã .
L 1Rate Lift speed 3 … 12 12 mm/s
³ À .
S hRate Turning speed of the rack 3 … 20 20 ang. degrees/s
³
À.
Ma nStop Reaction to manual stop –
à .
R emCtl Command via remote interface 14 bit (1, 0 or *)
À .
RS Ctl Command via RS232 interface 14 ASCII characters
&Config
&C onfig Instrument configuration –
³
Ã.
A ux General instrument settings General instrument settings –
³ Ã .
L anguage
³ ³
Dialog language english , deutsch, francais,
español
³ Ã .
C ontrast Display contrast 0 … 3 … 7
³ Ã .
B eeper Beeper on/off on , off
³ Ã .
D evName Device label 8 ASCII characters
³ Ã .
P rog Number of program version read only
³ À .
M axLift Maximum lift height 0 … 125 mm
³
Ã.
R ackDef Rack definitions –
³ Ã .
R ackNo Rack number 1 … 16
³ Ã .
C ode Rack code 000001 … 111111 (6 bit)
³ Ã .
T ype Rack type M129-2 , …
³ Ã .
W orkH Working position 0 … 125 mm
³ Ã .
Ri nseH Rinsing position 0 … 125 mm
³ Ã .
S hiftH Shift position 0 mm
³ Ã .
Sp ecialH Special position 0 … 125 mm
³ ³
³ À .
Spez Beak Special beaker positions –
³ Ã .
1 Special beaker 1 –
³ ³ À .
P os
³ :
Beaker position 0 … number of rack positions
³ À .
8 Special beaker 8 –
³ À .
P os Beaker position 0 … number of rack positions
³
Ã.
P osTab Position table –
³ Ã .
I dx
³ *
Index of the table.
Each table contains the following data:
0 … 31
³ Ã .
N ame Name position table 8 ASCII characters
³ Ã .
R 1Num Highest beaker position in row 1 2 … (R2Num – 2 )
³ Ã .
R2 2Num Highest beaker position in row 2 (R1Num + 2) … (R3Num – 2 )
³ Ã .
R3 3Num Highest beaker position in row 3 (R12Num + 2) … 200
