Introduction to Programming
Chapter 4
4Ć20
Table 4.D
Editing Functions 1
Function Mode Key Sequence Description
Inserting a Condition
Instruction
Program [INSERT] [Instruction]
[Address]
or
[INSERT] [ ← ] [Instruction]
[Address]
Position the cursor on the instruction that will precede the
instruction to be inserted. Then press key sequence. 2
Position the cursor on the instruction that will follow the
instruction to be inserted. Then press key sequence. 2
Removing a Condition
Instruction
Program [REMOVE] [Instruction] Position the cursor on the instruction to be removed and
press the key sequence.
Inserting a Rung Program [INSERT] [RUNG] Position the cursor on any instruction in the preceding rung
and press the key sequence. Enter the appropriate
instructions to complete the rung.
Removing a Rung Program [REMOVE] [RUNG] Position the cursor anywhere on the rung to be removed
and press the key sequence.
NOTE: Only addresses corresponding to OUTPUT
ENERGIZE, LATCH, and UNLATCH instructions are
cleared to zero when the rung is removed.
Change data of a word or
block instruction
Program [INSERT] [Data]
[CANCEL COMMAND]
Position the cursor on the word or block instruction whose
data is to be changed. Press the key sequence.
To terminate.
Change data of a word or
block instruction ONĆLINE
Run/Program [SEARCH] [5] [1] [Data]
[INSERT]
[CANCEL COMMAND]
Position the cursor on the word or block instruction whose
data is to be changed. Press the key sequence. Cursor
keys can be used as needed.
Press [INSERT] to enter the new data into memory.
To terminate.
Change the address of a
word or block instruction
Program [INSERT] [First Digit] [ ← ]
[Address]
[CANCEL COMMAND]
Position the cursor on a word or block instruction with data
and press [INSERT]. Enter the first digit of the first data
value of the instruction. Then use the [ ↑ ] and [ ↓ ] key as
needed to cursor up to the word address. Enter the
appropriate digits of the word address.
To terminate.
1 These functions can also be used during OnĆLine Programming (Refer to Section 4.4.5).
2 When bit address exceeds 5 digits, press the [EXPAND ADDR] key before entering address and enter a leading zero, if necessary.
Inserting an Instruction
Only nonoutput instructions can be inserted in a rung. There are two ways
of doing this.
One way is to press the key sequence [INSERT] [Key sequence of
instruction] [Key sequence of address]. The new instruction will be
inserted after the cursor’s present position. If an instruction is to be entered
at the beginning of a rung, the cursor can be positioned on the previous
rung’s output instruction. If the cursor is on the END statement, however,
