Data Transfer File Instructions

Chapter 12

12Ć28

Table 12.F

Data Entry Commands

Key Sequence

Explanation

[D] [D] [D] [D]

1

Data is entered or changed in the Command Buffer.

[INSERT]

Command Buffer data is loaded into Processor memory and

placed into the file word located by the Field Cursor.

[CANCEL COMMAND]

Terminates Data Monitor Mode and returns display to Ladder

Diagram. If in OnĆLine Data Change, [CANCEL COMMAND]

will terminate OnĆLine Data Change. A second [CANCEL

COMMAND] will terminate Data Monitor mode.

1

Hexadecimal format. The Binary format (1's and 0's) would contain 16 data characters.
