Data Table
Chapter 3
3Ć19
Figure 3.5
Instruction Address Terminology
Concept Example
Hardware Terminology Hardware Terminology
Input (1) or Output (0)
Rack No. (1Ć7)
I/O Group No.
(0Ć7)
Terminal No.
(00Ć07, 10Ć17)
Word
Address
Bit
Address
Data Table Terminology Instruction Address
Output: 0
Rack No.: 1
Word
Address
Bit
Address
I/O Group No.: 0
Terminal No.: 12
