background image

Report Generation

Chapter 9

9Ć9

Table 9.D

Alphanumeric/Graphic Keytop Definitions

Key

Function

[LINE FEED]

Moves the cursor down one line in the same column.

[RETURN]

Returns the cursor to the beginning of the next line.

[RUB OUT]

Deletes the last character or control code that was entered.

[REPT LOCK]

Allows the next character that is pressed to be repeated

continuously until [REPT LOCK] is pressed again.

[SHIFT]

Allows the next key pressed to be a shift character.

[SHIFT LOCK]

Allows all subsequent keys pressed to be shift characters until

[SHIFT] or [SHIFT LOCK] is pressed.

[CTRL]

Used as part of a key sequence to generate a control code.

[ESC]

Terminates the present function.

[MODE SELECT]

Terminates all functions and returns the Mode Select display to

the screen.

Blank Yellow Keys

Space keys. Move the cursor one position to the right.
