Configuring the I/O 4-37
20-COMM-E EtherNet/IP Adapter User Manual
Publication 20COMM-UM010G-EN-P
Create SLC 500 Ladder Logic for the Logic Command, Reference, and Datalink In
1. Insert another separate rung.
2. Double-click the rung to display the rung editor.
3. Enter MSG WRITE 500CPU LOCAL Nxx:n, where:
xx is an unused data file number (for example, N12:n), and
n is an unused element of the data file chosen for xx (for example, N12:0)
4. Press Enter.
5. Insert another separate rung.
6. Double-click the rung to display the rung editor.
7. Enter BST XIC Nxx:n/DN NXB XIC Nxx:n/ER BND OTU Nxx:n/
EN, where:
xx and n must correspond to the assigned data file number and element
(for example, N12:0) for the message created in steps 1…4.
Important: The information must be entered with appropriate numbers
for ‘xx’ and ‘n’ for your application, and with spaces and
forward slashes exactly as shown.
8. Press Enter.
9. In the MSG instruction ( Figure 4.17 ), double-click Setup Screen to
launch the message configuration screen ( Figure 4.18 ).
Figure 4.17 SLC 500 Ladder Logic for the Logic Command, Reference, and
Datalink In
10. Configure the General tab field by entering or verifying the information
shown in the message configuration screen.
Steps 1…4
Steps 5…8
Step 9
