B-6 Adapter Parameters
20-COMM-E EtherNet/IP Adapter User Manual
Publication 20COMM-UM010G-EN-P
41 [Peer Flt Action]
Sets the action that the adapter and drive will take
if the adapter detects that peer I/O communication
has been disrupted. This setting is effective only if
I/O is transmitted through the adapter.
Default: 0 = Fault
Values: 0 = Fault
1 = Stop
2 = Zero Data
3 = Hold Last
4 = Send Flt Cfg
Type: Read/Write
Reset Required: No
42
43
44
45
[Peer Inp Addr 1]
[Peer Inp Addr 2]
[Peer Inp Addr 3]
[Peer Inp Addr 4]
Sets the IP address bytes that specifies the device
from which the adapter receives (consumes) peer
I/O data.
Important: The Peer Inp Addr must be on the
same subnet as the 20-COMM-E. See IP
Addresses on page G-5 for more information.
Changes to these parameters are ignored when
Parameter 47 - [Peer Inp Enable] is set to ‘1’ (On).
Default: 0
Default: 0
Default: 0
Default: 0
Minimum: 0
Maximum: 255
Type: Read/Write
Reset Required: No
46 [Peer Inp Timeout]
Sets the timeout for a peer I/O connection. If the
time is reached without the adapter receiving
(consuming) a message, the adapter will respond
with the action specified in Parameter 41 - [Peer
Flt Action].
In an adapter receiving (consuming) peer I/O, the
value of this parameter must be greater than the
product of the value of Parameter 52 - [Peer Out
Time] in the adapter transmitting (producing) peer
I/O multiplied by the value of Parameter 53 - [Peer
Out Skip] in the adapter transmitting (producing)
peer I/O.
Default: 10.00 Seconds
Minimum: 0.01 Seconds
Maximum: 10.00 Seconds
Type: Read/Write
Reset Required: No
47 [Peer Inp Enable]
Determines if peer I/O input is on or off. Default: 0 = Off
Values: 0 = Off
1 = On
Type: Read/Write
Reset Required: No
Parameter
No. Name and Description
Details
!
ATTENTION: Risk of injury or equipment damage exists. Parameter 41 - [Peer
Flt Action] lets you determine the action of the adapter and connected drive if
the adapter is unable to communicate with the designated peer. By default, this
parameter faults the drive. You can set this parameter so that the drive continues
to run, however, precautions should be taken to verify that the setting of this
parameter does not create a risk of injury or equipment damage. When
commissioning the drive, verify that your system responds correctly to various
situations (for example, a disconnected cable).
255.255.255.255
[Peer Inp Addr 1]
[Peer Inp Addr 2]
[Peer Inp Addr 3]
[Peer Inp Addr 4]
