Page 44
3-16
Configuring the Adapter
20-COMM-E EtherNet/IP Adapter User Manual
Publication 20COMM-UM010G-EN-P
Series B Adapter (Firmware Revision 3.xxx or Later)
By default, the Series B adapter web pages are disabled. See
set the Web Pages Switch (SW2) to the ‘Enable Web’ (up) position.
Important: For a change to the switch setting to take effect, the adapter
Resetting the Adapter on page 3-16
).
Bit 0 of Parameter 56 - [Web Features] is used to protect the configured
settings for e-mail messaging. By default, settings are not protected and the
user can make changes. To protect the configured settings, set the value of
E-mail Cfg Bit 0 to ‘0’ (Disabled). You can unprotect the configuration by
changing Bit 0 back to ‘1’ (Enabled). E-mail messaging will always remain
active regardless of whether or not its settings are protected—unless e-mail
messaging was never configured. For more information about configuring
adapter e-mail messaging or to stop e-mail messages, see
Notification Web Page on page 8-6
Bit 0 is the right-most bit. It is highlighted above and equals ‘1’.
Changes to this parameter take effect immediately. A reset is not required.
Resetting the Adapter
Changes to switch settings and some adapter parameters require that you
reset the adapter before the new settings take effect. You can reset the adapter
by power cycling the drive or by using Parameter 20 - [Reset Module].
Set Parameter 20 - [Reset Module] to ‘1’ (Reset Module).
When you enter ‘1’ (Reset Module), the adapter will be immediately reset.
When you enter ‘2’ (Set Defaults), the adapter will set all adapter
parameters to their factory-default values. After performing a Set Defaults,
enter ‘1’ (Reset Module) so that the new values take effect. The value of this
parameter will be restored to ‘0’ (Ready) after the adapter is reset.
Bit
Description
0
E-mail Cfg (Default = 1 = Enabled)
1…7
Not Used
Port 5 Device
20-COMM-E
Parameter #: 56
Web Features
x x x x x x x x x x x x x x x
1
E-mail Cfg
b00
!
ATTENTION: Risk of injury or equipment damage exists. If the
adapter is transmitting control I/O to the drive, the drive may fault
when you reset the adapter. Determine how your drive will
respond before resetting a connected adapter.
Value
Description
0
Ready (Default)
1
Reset Module
2
Set Defaults
Port 5 Device
20-COMM-E
Parameter #: 20
Reset Module
1
Reset Module
