Using the I/O

5-23

20-COMM-E EtherNet/IP Adapter User Manual

PowerFlex 70, PowerFlex 700 with Standard Control, and PowerFlex 700H Drives

When using any of these products—which all contain INT (16-bit format)
data types—you will read from and write to the MSW data table address in
the controller.

Table 5.G Controller Data Table Addresses for:

PowerFlex 70 Drives with Standard or Enhanced Control

PowerFlex 700 Drives with Standard Control

PowerFlex 700H Drives

Data Table Address Description
N20:1

Logic Status (see

Appendix D

)

N20:2

Reserved

N20:3

Speed Feedback

N20:4

Value of parameter assigned to Parameter 310 [Data Out A1] LSW

N20:5

Value of parameter assigned to Parameter 310 [Data Out A1] MSW

N20:6

Value of parameter assigned to Parameter 311 [Data Out A2] LSW

N20:7

Value of parameter assigned to Parameter 311 [Data Out A2] MSW

N20:8

Value of parameter assigned to Parameter 312 [Data Out B1] LSW

N20:9

Value of parameter assigned to Parameter 312 [Data Out B1] MSW

N20:10

Value of parameter assigned to Parameter 313 [Data Out B2] LSW

N20:11

Value of parameter assigned to Parameter 313 [Data Out B2] MSW

N20:12

Value of parameter assigned to Parameter 314 [Data Out C1] LSW

N20:13

Value of parameter assigned to Parameter 314 [Data Out C1] MSW

N20:14

Value of parameter assigned to Parameter 315 [Data Out C2] LSW

N20:15

Value of parameter assigned to Parameter 315 [Data Out C2] MSW

N20:16

Value of parameter assigned to Parameter 316 [Data Out D1] LSW

N20:17

Value of parameter assigned to Parameter 316 [Data Out D1] MSW

N20:18

Value of parameter assigned to Parameter 317 [Data Out D2] LSW

N20:19

Value of parameter assigned to Parameter 317 [Data Out D2] MSW

N20:20

Logic Command (see

Appendix D

)

N20:21

Reserved

N20:22

Speed Reference

N20:23

Value of parameter assigned to Parameter 300 [Data In A1] LSW

N20:24

Value of parameter assigned to Parameter 300 [Data In A1] MSW

N20:25

Value of parameter assigned to Parameter 301 [Data In A2] LSW

N20:26

Value of parameter assigned to Parameter 301 [Data In A2] MSW

N20:27

Value of parameter assigned to Parameter 302 [Data In B1] LSW

N20:28

Value of parameter assigned to Parameter 302 [Data In B1] MSW

N20:29

Value of parameter assigned to Parameter 303 [Data In B2] LSW

N20:30

Value of parameter assigned to Parameter 303 [Data In B2] MSW

N20:31

Value of parameter assigned to Parameter 304 [Data In C1] LSW

N20:32

Value of parameter assigned to Parameter 304 [Data In C1] MSW

N20:33

Value of parameter assigned to Parameter 305 [Data In C2] LSW

N20:34

Value of parameter assigned to Parameter 305 [Data In C2] MSW

N20:35

Value of parameter assigned to Parameter 306 [Data In D1] LSW

N20:36

Value of parameter assigned to Parameter 306 [Data In D1] MSW

N20:37

Value of parameter assigned to Parameter 307 [Data In D2] LSW

N20:38

Value of parameter assigned to Parameter 307 [Data In D2] MSW
