Using the I/O

5-27

20-COMM-E EtherNet/IP Adapter User Manual

Publication 20COMM-UM010G-EN-P

Table 5.K Controller Data Table Addresses for PowerFlex 750-Series Drives

Data Table Address Description
N20:1

Logic Status (see

Appendix D

)

N20:2

Speed Feedback LSW

N20:3

Speed Feedback MSW

N20:4

Value of parameter assigned to Parameter 905 [Data Out A1] LSW

N20:5

Value of parameter assigned to Parameter 905 [Data Out A1] MSW

N20:6

Value of parameter assigned to Parameter 906 [Data Out A2] LSW

N20:7

Value of parameter assigned to Parameter 906 [Data Out A2] MSW

N20:8

Value of parameter assigned to Parameter 907 [Data Out B1] LSW

N20:9

Value of parameter assigned to Parameter 907 [Data Out B1] MSW

N20:10

Value of parameter assigned to Parameter 908 [Data Out B2] LSW

N20:11

Value of parameter assigned to Parameter 908 [Data Out B2] MSW

N20:12

Value of parameter assigned to Parameter 909 [Data Out C1] LSW

N20:13

Value of parameter assigned to Parameter 909 [Data Out C1] MSW

N20:14

Value of parameter assigned to Parameter 910 [Data Out C2] LSW

N20:15

Value of parameter assigned to Parameter 910 [Data Out C2] MSW

N20:16

Value of parameter assigned to Parameter 911 [Data Out D1] LSW

N20:17

Value of parameter assigned to Parameter 911 [Data Out D1] MSW

N20:18

Value of parameter assigned to Parameter 912 [Data Out D2] LSW

N20:19

Value of parameter assigned to Parameter 912 [Data Out D2] MSW

N20:20

Logic Command (see

Appendix D

)

N20:21

Speed Reference LSW

N20:22

Speed Reference MSW

N20:23

Value of parameter assigned to Parameter 895 [Data In A1] LSW

N20:24

Value of parameter assigned to Parameter 895 [Data In A1] MSW

N20:25

Value of parameter assigned to Parameter 896 [Data In A2] LSW

N20:26

Value of parameter assigned to Parameter 896 [Data In A2] MSW

N20:27

Value of parameter assigned to Parameter 897 [Data In B1] LSW

N20:28

Value of parameter assigned to Parameter 897 [Data In B1] MSW

N20:29

Value of parameter assigned to Parameter 898 [Data In B2] LSW

N20:30

Value of parameter assigned to Parameter 898 [Data In B2] MSW

N20:31

Value of parameter assigned to Parameter 899 [Data In C1] LSW

N20:32

Value of parameter assigned to Parameter 899 [Data In C1] MSW

N20:33

Value of parameter assigned to Parameter 900 [Data In C2] LSW

N20:34

Value of parameter assigned to Parameter 900 [Data In C2] MSW

N20:35

Value of parameter assigned to Parameter 901 [Data In D1] LSW

N20:36

Value of parameter assigned to Parameter 901 [Data In D1] MSW

N20:37

Value of parameter assigned to Parameter 902 [Data In D2] LSW

N20:38

Value of parameter assigned to Parameter 902 [Data In D2] MSW
