Figure 8.7 – Rockwell Automation 20-COMM-E PowerFlex EtherNet/IP Adapter User Manual
Page 216
8-8
Viewing the Adapter Web Pages
20-COMM-E EtherNet/IP Adapter User Manual
Publication 20COMM-UM010G-EN-P
Figure 8.6 DOS Window Example Showing E-mail Server IP Address
f.
Type the IP address shown in the DOS window (for this example,
131.200.78.4) into the E-mail Notification Web Page (
Figure 8.4
).
3. Click Save changes.
Important: After configuring E-mail Notification, we recommend
protecting the settings. Otherwise the configuration can be
changed anytime the web page is accessed with a browser. To
protect the settings, do the following:
• Series A Adapters—Use Parameter 54 - [Access Control] to set E-mail
Config Bit 1 value to ‘0’ (Disabled).
• Series B Adapters—Use Parameter 56 - [Web Features] to set E-mail
Cfg Bit 0 value to ‘0’ (Disabled).
shows an example e-mail message automatically sent by the
adapter in response to selected events.
Figure 8.7 Example of E-mail Message Sent by the Adapter
TIP: To stop e-mail messages, uncheck all of the ‘Send an e-mail message
when…’ boxes.
• For Series A adapters, disabling the adapter web pages by setting
Parameter 54 - [Access Control] Web Enable Bit 0 to ‘0’ (Disabled)
will not stop the adapter from sending e-mail messages.
• For Series B adapters, disabling the adapter web pages by setting the
Web Pages Switch (SW2 in
) to the ‘Disable Web’ position
will not stop the adapter from sending e-mail messages.
