20-COMM-E EtherNet/IP Adapter User Manual
Publication 20COMM-UM010G-EN-P
Chapter 3
Configuring the Adapter
This chapter provides instructions and information for setting the
parameters in the adapter.
For a list of parameters, see Appendix B , Adapter Parameters . For
definitions of terms in this chapter, see the Glossary .
Configuration Tools
The adapter stores parameters and other information in its own nonvolatile
storage (NVS) memory. You must, therefore, access the adapter to view and
edit its parameters. The following tools can be used to access the adapter
parameters.
Topic Page
Configuration Tools 3-1
Using the PowerFlex 7-Class HIM to Access Parameters 3-2
Using BOOTP Server to Set the IP Address, Subnet Mask, and Gateway Address 3-3
Using Parameters to Set the IP Address, Subnet Mask, and Gateway Address 3-5
Setting the Data Rate 3-7
Setting the I/O Configuration 3-7
Selecting Master-Slave or Peer-to-Peer Hierarchy 3-8
Setting the Reference Adjustment 3-13
Setting a Fault Action 3-14
Setting Web Access Control 3-15
Resetting the Adapter 3-16
Viewing the Adapter Status Using Parameters 3-17
Updating the Adapter Firmware 3-17
Tool See
PowerFlex 7-Class HIM page 3-2
BOOTP Server page 3-3
Connected Components Workbench
software, version 1.02 or later
http://www.ab.com/support/abdrives/webupdate/
software.html , or online help (installed with the software)
DriveExplorer software,
version 2.01 or later
http://www.ab.com/drives/driveexplorer , or online help
(installed with the software)
DriveExecutive software,
version 3.01 or later
http://www.ab.com/drives/drivetools , or online help
(installed with the software)
