7-2 Troubleshooting
20-COMM-E EtherNet/IP Adapter User Manual
Publication 20COMM-UM010G-EN-P
PORT Status Indicator
This red/green bicolor LED indicates the status of the adapter’s connection
to the drive as shown in the table below.
MOD Status Indicator
This red/green bicolor LED indicates the status of the adapter as shown in
the table below.
Status Cause Corrective Action
Off The adapter is not powered or is not properly
connected to the drive.
• Securely connect the adapter to the drive using the Internal Interface
(ribbon) cable.
• Apply power to the drive (or adapter if mounted in a DPI External
Comms Kit).
Flashing Red The adapter is not receiving a ping message from
the drive.
• Verify that cables are securely connected and not damaged.
Replace cables if necessary.
• Cycle power to the drive (or adapter if mounted in a DPI External
Comms Kit).
Steady Red The drive has refused an I/O connection from the
adapter.
Another DPI peripheral is using the same DPI port
as the adapter.
Important: Cycle power to the drive (or adapter if mounted in a DPI
External Comms Kit) after making any of the following corrections:
• Verify that all DPI cables on the drive are securely connected and not
damaged. Replace cables if necessary.
• Verify that the DPI drive supports Datalinks.
• Configure the adapter to use a Datalink that is not already being
used by another peripheral.
Steady Orange The adapter is connected to a product that does
not support Allen-Bradley DPI communications.
Connect the adapter to a product that supports Allen-Bradley DPI
communications (for example, a PowerFlex 7-Class drive).
Flashing Green The adapter is establishing an I/O connection to
the drive.
No action required. Normal behavior if no DPI I/O is enabled.
Steady Green The adapter is properly connected and is
communicating with the drive.
No action required.
Status Cause Corrective Action
Off The adapter is not powered or is not properly
connected to the drive.
• Securely connect the adapter to the drive using the Internal Interface
(ribbon) cable.
• Apply power to the drive (or adapter if mounted in a DPI External
Comms Kit).
Flashing Red The adapter has failed the firmware test.
The adapter firmware is being updated.
• Clear faults in the adapter.
• Cycle power to the drive (or adapter if mounted in a DPI External
Comms Kit).
• If cycling power does not correct the problem, the adapter parameter
settings may have been corrupted. Reset defaults and reconfigure
the adapter.
• If resetting defaults does not correct the problem, update the adapter
with the latest firmware revision.
Steady Red The adapter has failed the hardware test. • Cycle power to the drive (or adapter if mounted in a DPI External
Comms Kit).
• Replace the adapter.
Flashing Green The adapter is operational, but is not transferring
I/O data to a controller.
• Place the scanner in RUN mode.
• Program the controller to recognize and transmit I/O to the adapter.
• Configure the adapter for the program in the controller.
• Normal behavior if no DPI I/O is enabled.
Steady Green The adapter is operational and transferring I/O
data to a controller.
No action required.
