20-COMM-E EtherNet/IP Adapter User Manual
Publication 20COMM-UM010G-EN-P
Chapter 4
Configuring the I/O
This chapter provides instructions on how to configure a Rockwell
Automation ControlLogix, PLC-5, SLC 500, or MicroLogix 1100/1400
controller to communicate with the adapter and connected PowerFlex drive.
Using RSLinx Classic
Software
RSLinx Classic software, in all its variations (Lite, Gateway, OEM, and so
forth), is used to provide a communication link between the computer,
network, and controller. RSLinx Classic software requires its
network-specific driver to be configured before communication is
established with network devices. To configure the RSLinx driver, follow
this procedure.
1. Start RSLinx Classic software and select Communications >
Configure Drivers to display the Configure Drivers screen.
2. From the Available Driver Types pull-down menu, choose EtherNet/IP
Driver.
3. Click Add New… to display the Add New RSLinx Driver screen.
4. Use the default name or type a new name and click OK.
The ‘Configure driver:’ screen appears.
5. Depending on your application, select either the browse local or remote
subnet option.
6. Click OK.
Topic Page
Using RSLinx Classic Software 4-1
ControlLogix Controller Example 4-2
Limitations Using a PLC-5, SLC 500, or MicroLogix 1100/1400 Controller 4-22
PLC-5 Controller Example 4-23
SLC 500 Controller Example 4-31
MicroLogix 1100/1400 Controller Example 4-39
