Ion Operations Manual
{Device Details} - appears when the current address is patched to a RDM device. RDM devices
must be enabled through the ECU and discovered through the patch. See
, and
{Device Details} displays the information that it receives from the device and allows some changes
to be made to:
•
Device Label (displayed at the top by the address number)
•
DMX Address (can be changed in this display by clicking on the property or value)
•
DMX Label (same as the device label, but the label can be changed here by clicking on
the property or value)
•
Type
•
Manufacturer
•
Device ID
•
Footprint
•
Version
•
Lamp State
•
Lamp Hours
•
Head DC Voltage
•
Lamp On/Off
•
Gel Distance Traveled
•
Gel2 Distance Traveled
•
Fan RPM
•
Ambient Temperature
•
Gel Temperature
•
Device Errors (will only display if there are current errors)
•
Clear Errors
Device Errors are displayed in four different colors depending on severity.
•
Gray - unknown or not an error
•
White - Advisory
•
Yellow - Warning
•
Red - Error
N o t e :
Changes may take a few seconds to take effect. They will propagate to the RDM
device and then back to the console’s patch and about displays.
N o t e :
Changing the address can not cause any part of the fixture to move to a different
universe or communication with the device may be lost. The universe is set into
the gateways port configuration.
N o t e :
Details displayed will vary based on the device.
N o t e :
Color severity is determined by the device manufacturer.
