Page 28
12
Ion Operations Manual
Console Geography
Below is a diagram of the Ion console with references made to specific areas of use. The terms and
names for each area and interface are used throughout this manual.
Parameter category/
encoder page buttons
Power button
USB port
Level
wheel
Navigation keys
Paged encoders
Control
keypad
Playback
controls
LCD screen
Blackout and
Grandmaster
Softkeys
VGA port
DVI video
ports
IEC receptacle
MIDI Out and In
Hard power switch
Ethernet
port
DMX ports
1 and 2
USB
ports
Remote
trigger
port
Phone
Remote
Port
Current Ion
Rear panel
Audio Ports
(not currently
supported)
VGA port
(blue)
Dual DVI video
port (white)
IEC receptacle
MIDI Out and In
Hard power switch
Ethernet
port
DMX ports
1 and 2
USB
ports
Remote
trigger
port
Phone
Remote
Port
Original Ion
Rear panel
Audio Ports
(not currently
supported)
